Technical Data

Nominal Output Power:

330 watts RMS @ 8 ohms

660 watts RMS @ 4 ohms

1320 watts RMS @ 2 ohms

A/B Class

Total Harmonic Distortion (THD):

 < 0,01 % from 5 Hz to 100 kHz


Analog Input:

2 x XLR > 47 kohms

2 x XLR bypass output

Signal to noise ratio:

 > 116 dB (A) @ nominal power


Gain:

32 dB for maximal out

Power consumption:

2,5 watts Standby, 40 watts @ idle, 2500 watts @ maximum output power


Speaker Output Impedance:

< 0.2 ohms from 10 Hz to 40 kHz (measured in 8 ohms)

Size in mm:

440 x 447 x 216 (WxDxH)


Frequency Response:

1.0 Hz - 300 kHz, ± 0,1 dB

Size in inches:

17,33 x 17,60 x 8,5 (WxDxH)


Slew Rate:

> 1300 V/µs

Net weight:

45 Kg


DC Output Voltage:

± 15 mV

Fuse ratings:

115 volts: 20A (T)

230 volts: 10A (T)

Factory selectable
