Technical Data

Line Gain:

Up to + 10 dB

Signal to noise ratio:

> 101 dB (A)


Analog Input Impedances:



4 x RCA line 47 kohms, from 5 Hz to 100 kHz

4 x XLR Line 47 kohms, from 5 Hz to 100 kHz

1 x optional future imput slot

Power consumption:

5 - 60 watts depending on working conditions


Line Output impedances:



RCA 30 ohms

XLR 600 ohms

REC OUT < 100 ohms

Remote control:

full functions


Frequency Response:

 1 Hz - 300 kHz, ± 0,2 dB

Size in mm:

440 x 335 x 136 (WxDxH)


Rise Time:

 < 0.8 µs

Size in inches:

17,33 x 13,19 x 5,35 (WxDxH)


Slew Rate:

> 34 V/µs

Net weight:

15 kg


Total Harmonic Distortion (THD):

< 0,001 % from 10 Hz to 100 kHz max out + 18 dBu

Fuse ratings:

115 volts: 20A (T)

230 volts: 10A (T)

Factory selectable


Crosstalk:

< - 90 dB from 20Hz to 20kHz
